LayerBlending

https://github.com/leegoonz/LayerBlenderShader.git

Shader "Tianyu Shaders/Ground/TextureBlend/Texture Blender 3 Layered"
{
    Properties
    {


        [Header(DIFFUSE COLOR FETCH)]
    _Layer1Color("Background Color", Color) = (1,1,1,1)
        _Layer1Albedo("Layer1 (RGB)", 2D) = "gray" {}
    [Header(DIFFUSE LAYER FETCH)]
    _Layer2Color("Layer2 Color", Color) = (1,1,1,1)
        _Layer2Albedo("Layer2 (RGB)", 2D) = "gray" {}
    _Layer3Color("Layer3 Color", Color) = (1,1,1,1)
        _Layer3Albedo("Layer3 (RGB)", 2D) = "gray" {}
    _BlendValue("Layer2 Mix Scale (Range)",Range(0.01,1)) = 0.5
        _BlendValue2("Layer3 Mix Scale (Range)",Range(0.01,1)) = 0.5
        [Space][Space][Space][Space][Space]
        [Header(SPECULAR FETCH)]
    _SpecColor("Specular Color", Color) = (0.5, 0.5, 0.5, 1)
        _Shininess("Shininess", Range(0.15, 1)) = 0.2
        [HideInInspector]
    _Layer1Specular("Layer1(R)",2D) = "gray" {}
    _SpecularLayer1Power("Specular Layer1 Power" ,Range(0.1 , 10)) = 5.0
        [Space][Space][Space]

        [HideInInspector]
    _Layer2Specular("Layer2(R)",2D) = "gray" {}
    _SpecularLayer2Power("Specular Layer2 Power" ,Range(0.1 , 10)) = 5.0
        [HideInInspector]
    _BlendValueSpec("Specular Scale (Range)",Range(0.01,1)) = 0.5
        [Space][Space][Space][Space][Space]
        [Header(NORMALMAP FETCH)]
    _BumpMap("Normalmap Layer1", 2D) = "bump" {}
    _bumpScale("Layer1 Normal Scale", Range(1.0,2.0)) = 1.0
        _BumpMap2("Normalmap Layer2", 2D) = "bump" {}
    [Space][Space][Space][Space][Space]
        [Header(PARAMETER FETCH)]
    _ParamTex("Layer 2 mask(R) , Layer3 mask(G) , AlphaBelnding mask (B)", 2D) = "white" {}


    }

        SubShader
    {
        Tags{ "RenderType" = "Opaque" }
        LOD 400

        CGPROGRAM
#pragma debug
#pragma fragmentoption ARB_precision_hint_fastest
#pragma surface surf BlinnPhong novertexlights
#pragma target 3.0
#include "UnityCG.cginc"


        sampler2D_half    _Layer1Albedo;
    sampler2D_half    _Layer2Albedo;
    sampler2D_half    _Layer3Albedo;

    sampler2D_half    _Layer1Specular;
    sampler2D_half    _Layer2Specular;

    fixed _SpecularLayer1Power;
    fixed _SpecularLayer2Power;

    sampler2D_half    _BumpMap;
    sampler2D_half    _BumpMap2;
    sampler2D_half    _ParamTex;

    fixed4 _Layer1Color;
    fixed4 _Layer2Color;
    fixed4 _Layer3Color;
    fixed _Shininess;
    fixed _BlendValue;
    fixed _BlendValue2;
    fixed _BlendValueSpec;
    fixed _bumpScale;

    struct Input
    {
        half2 uv_Layer1Albedo;
        half2 uv_Layer2Albedo;
        half2 uv_Layer3Albedo;
        half2 uv_ParamTex;
        //INTERNAL_DATA
    };



    void surf(Input IN, inout SurfaceOutput o)
    {
        fixed4 layer1tex = tex2D(_Layer1Albedo, IN.uv_Layer1Albedo);
        fixed4 layer2tex = tex2D(_Layer2Albedo, IN.uv_Layer2Albedo);
        fixed4 layer3tex = tex2D(_Layer3Albedo, IN.uv_Layer3Albedo);

        //fixed layer1spec = tex2D(_Layer1Specular, IN.uv_Layer1Albedo);
        //fixed layer1spec = layer1tex.r * _SpecularLayer1Power;
        //fixed layer1spec = pow(layer1tex.r , _SpecularLayer1Power);
        fixed layer1spec = _SpecularLayer1Power * (layer1tex.r * 0.175);
        //fixed layer2spec = tex2D(_Layer2Specular, IN.uv_Layer2Albedo);
        //fixed layer2spec = layer2tex.r * _SpecularLayer2Power;
        //fixed layer2spec = pow(layer2tex.r , _SpecularLayer2Power);
        fixed layer2spec = _SpecularLayer2Power * (layer2tex.r * 0.175);

        fixed4 param_tex = tex2D(_ParamTex, IN.uv_ParamTex);

        fixed4 bump = (tex2D(_BumpMap, IN.uv_Layer1Albedo)) * _bumpScale;
        fixed4 bump2 = tex2D(_BumpMap2, IN.uv_Layer2Albedo);

        fixed layer2Mask = param_tex.r;
        fixed layer3Mask = param_tex.g;


        layer1tex *= (1 - (_BlendValue * layer2Mask));
        layer2tex *= (_BlendValue * layer2Mask);
        fixed3 layerCom = (layer1tex.rgb * _Layer1Color.rgb) + (layer2tex * _Layer2Color).rgb;
        layerCom = layerCom * (1 - (_BlendValue2 * layer3Mask));
        layer3tex = layer3tex * (_BlendValue2 * layer3Mask);

        layer1spec *= (1 - (_BlendValue * 1 * layer2Mask));
        layer2spec *= (_BlendValue * 1 * layer2Mask);




        bump *= (1 - (_BlendValue * layer2Mask));
        bump2 *= (_BlendValue * layer2Mask);
        bump = bump + bump2;

        o.Albedo = layerCom.rgb + (layer3tex * _Layer3Color);
        o.Gloss = layer1spec + layer2spec;
        o.Normal = UnpackNormal(normalize(bump));
        o.Specular = _Shininess;

    }
    ENDCG
    }
        FallBack "Diffuse"
}
